CHAPTER 10: VLAN
Converting Port VLAN to Tag VLAN (continued)
-----------------------------------------------
PORT | MODE
-----------------------------------------------
1 | UNTAGGED |
2 | UNTAGGED |
6 | UNTAGGED |
7 | UNTAGGED |
VLAN ID: 10
Name : engineering
Status : Active
-----------------------------------------------
PORT | MODE
-----------------------------------------------
3 | UNTAGGED |
4 | UNTAGGED |
5 | UNTAGGED |
VLAN ID: 20
Name : sales
Status : Active
-----------------------------------------------
PORT | MODE
-----------------------------------------------
3 | UNTAGGED |
4 | UNTAGGED |
5 | UNTAGGED |
VLAN ID: 30
Name : marketing
Status : Active
-----------------------------------------------
PORT | MODE
-----------------------------------------------
3 | UNTAGGED |
4 | UNTAGGED |
5 | UNTAGGED |
ML1200(tag-vlan)##
Port tagging enabled
ML1200(tag-vlan)##
Port tagging enabled
ML1200(tag-vlan)##
Port tagging enabled
ML1200(tag-vlan)##
VLAN ID: 1
Name : Default VLAN
Status : Active
(continued on next page)
MULTILINK ML1200 MANAGED FIELD SWITCH – INSTRUCTION MANUAL
| STATUS
UP
DOWN
DOWN
UP
| STATUS
DOWN
DOWN
DOWN
| STATUS
DOWN
DOWN
DOWN
| STATUS
DOWN
DOWN
DOWN
set-port port=3-5 tagging id=10 status=tagged
set-port port=3-5 tagging id=20 status=tagged
set-port port=3-5 tagging id=30 status=tagged
show vlan type=tag
Enable filtering on the ports required. The
software will prompt to ensure that
connectivity is not disrupted.
VLANs are now active. However, as the
packet traverses VLANs, the packet should
be tagged. This is enabled next.
VLAN
10–17
