show ib sm port
Table 6-41
Field
VL-arb-high-cap
VL-arb-low-cap
mtu-cap
VL-stall-count
HOQ-life
oper-VL
in-part-enforce
out-part-enforce
in-filter-raw-pkt-enforce
out-filter-raw-pkt-enforce Boolean value that indicates whether or not to support optional raw packet
mkey-violation
pkey-violation
Cisco SFS 7000 Series Product Family Command Reference Guide
6-118
show ib sm port Command Field Descriptions (continued)
Description
Highest arbitration value allowed by the arbiter in determining the next
packet in a set of packets to send across the link. Used with the virtual-lane
arbitration table and specified as a VL/Weight pair. See section 14.2.5.9,
VL Arbitration Table, InfiniBand Architecture®, Vol. 1, Release 1.1, for
more information.
Lowest arbitration value allowed by the arbiter in determining the next
packet in a set of packets to send across the link. Used with the virtual-lane
arbitration table and specified as a VL/Weight pair. See section 14.2.5.9,
VL Arbitration Table, InfiniBand Architecture®, Vol. 1, Release 1.1, for
more information.
Used in conjunction with neighbor-mtu to determine the maximum
transmission size supported on this port. The lesser of mtu-cap and
neighbor-mtu determines the actual MTU used. The value appears as 256,
512, 1024, 2048, or 4096.
Number of sequentially dropped packets at which the port enters a
VLStalled state. The virtual lane exits the VLStalled state (8 * HLL) units
after entering it. See section 18.2.5.4, Transmitter Queuing, InfiniBand
Architecture®, Vol. 1, Release 1.1, for a description of HLL.
Maximum duration allowed to packets at the head of a virtual-lane queue.
Used with VL-stall-count to determine the outgoing packets to discard.
Administrative limit for the number of virtual lanes allowed to the link. Do
not set this above the VL-cap value. The value appears as vl0, vl0-Vl1,
vl0-Vl3, vl0-Vl7, or vl0-Vl14.
Boolean value that indicates whether or not to support optional partition
enforcement for the packets that were received by this port. No default
value applies.
Boolean value that indicates whether or not to support optional partition
enforcement for the packets transmitted by this port. No default value
applies.
Boolean value that indicates whether or not to support optional raw packet
enforcement for the raw packets that were received by this port. No default
value applies.
enforcement for the raw packets transmitted by this port. No default value
applies.
Number of subnet management packets (SMPs) that have been received on
this port with invalid M_Keys since initial power up or the last reset. See
section 14.2.4, Management Key, InfiniBand Architecture®, Vol. 1, Release
1.1, for more information.
Number of subnet management packets that have been received on this port
with invalid P_Keys since initial power up or the last reset. See section
9.2.7, partition key (P_KEY), InfiniBand Architecture®, Vol. 1, Release
1.1, for more information.
