Register Description
2.12.4 MC_RIR_WAY_CH2_0, MC_RIR_WAY_CH2_1
MC_RIR_WAY_CH2_2, MC_RIR_WAY_CH2_3
MC_RIR_WAY_CH2_4, MC_RIR_WAY_CH2_5
MC_RIR_WAY_CH2_6, MC_RIR_WAY_CH2_7
MC_RIR_WAY_CH2_8, MC_RIR_WAY_CH2_9
MC_RIR_WAY_CH2_10, MC_RIR_WAY_CH2_11
MC_RIR_WAY_CH2_12, MC_RIR_WAY_CH2_13
MC_RIR_WAY_CH2_14, MC_RIR_WAY_CH2_15
MC_RIR_WAY_CH2_16, MC_RIR_WAY_CH2_17
MC_RIR_WAY_CH2_18, MC_RIR_WAY_CH2_19
MC_RIR_WAY_CH2_20, MC_RIR_WAY_CH2_21
MC_RIR_WAY_CH2_22, MC_RIR_WAY_CH2_23
MC_RIR_WAY_CH2_24, MC_RIR_WAY_CH2_25
MC_RIR_WAY_CH2_26, MC_RIR_WAY_CH2_27
MC_RIR_WAY_CH2_28, MC_RIR_WAY_CH2_29
MC_RIR_WAY_CH2_30, MC_RIR_WAY_CH2_31
Channel Rank Interleave Way Range Registers. These registers allow the user to define
the ranks and offsets that apply to the ranges defined by the LIMIT in the
MC_RIR_LIMIT_CH registers. The mappings are as follows:
RIR_LIMIT_CH{chan}[0] -> RIR_WAY_CH{chan}[3:0]
RIR_LIMIT_CH{chan}[1] -> RIR_WAY_CH{chan}[7:6]
RIR_LIMIT_CH{chan}[2] -> RIR_WAY_CH{chan}[11:10]
RIR_LIMIT_CH{chan}[3] -> RIR_WAY_CH{chan}[15:14]
RIR_LIMIT_CH{chan}[4] -> RIR_WAY_CH{chan}[19:18]
RIR_LIMIT_CH{chan}[5] -> RIR_WAY_CH{chan}[23:22]
RIR_LIMIT_CH{chan}[6] -> RIR_WAY_CH{chan}[27:26]
RIR_LIMIT_CH{chan}[7] -> RIR_WAY_CH{chan}[31:28]
Device:
Function: 2
Offset:
C4h, C8h, CCh, D0h, D4h, D8h, DCh, E0h, E4h, E8h, ECh, F0h, F4h, F8h, FCh
Access as a Dword
Bit
13:4
3:0
Datasheet
6
80h, 84h, 88h, 8Ch, 90h, 94h, 98h, 9Ch, A0h, A4h, A8h, ACh, B0h, B4h, B8h, BCh, C0h,
Reset
Type
Value
OFFSET.
RW 0
This field defines the offset used in the rank interleave. This is a 2's
complement value.
RANK.
This field defines which rank participates in WAY(n). If MC.CLOSEDPAGE=1, this
field defines the DRAM rank selected when MemoryAddress[7:6]=(n). If
RW 0
MC.CLOSEDPAGE=0, this field defines which rank is selected when
MemoryAddress[13:12]=(n). (n) is the instantiation of the register. This field is
organized by physical rank. Bits [3:2] are the encoded DIMM ID(slot). Bits
[1:0] are the rank within that DIMM.
Description
91
