8. Insert the board into the front and rear retention mechanisms. Carefully push down on the
board until it engages and fully seats in the slot connector.
9. Close the front and rear latches.
10. Install the system board access cover and the rear access cover.
11. Turn on any peripheral devices connected to the system.
12. Connect the power cord and turn on power to the server.
Removing a PCI Add-In Board from a Non-Hot-Plug Slot
CAUTION
The PCI add-in board slots located under the system board access cover are
not hot-plug slots.
To remove a PCI add-in board from a non-hot-plug slot:
1. Disconnect the AC power cords from the power source or wall outlets.
2. Turn off all peripheral devices connected to the server system.
3. Remove the rear access cover (page 66) and the system board access cover (page 68).
4. Release the latches on the front and rear retention mechanisms.
5. Grasp the board by the top edge or corners, carefully pull it out of the connector, and slide it
free of the retention bracket.
6. If you are installing a new board, follow the instructions on page 97. If you are not installing
another PCI add-in board, continue with the next step below.
7. Install a slot cover over the vacant slot in the back panel.
8. Install the system board access cover and the rear access cover.
9. Turn on any peripheral devices connected to the system.
10. Connect the power cord and turn on power to the server.
98
Intel SPSH4 Server Platform Product Guide
