Cisco Firewall Devices (PIX, ASA, and FWSM)
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Add and Configure a Cisco Firewall Device in MARS
The process of adding a PIX security appliance, Cisco ASA, or FWSM to MARS involves many of the
same steps, regardless of the version of software that is running. The process is exactly the same for PIX
software versions 6.0, 6.1, 6.2, and 6.3. However, Cisco ASA, PIX 7.0, and FWSM provide the ability
to define multiple security contexts, or virtual firewalls.
Adding a Cisco ASA, PIX 7.0, and FWSM to MARS has two distinct steps. First, you must define the
settings for the admin context. Then, if multiple context mode is enabled, you define or discover the
settings for its security contexts. These Cisco firewall device have two type of contexts: one admin
context, which is used for configuration of the device itself, and one or more security contexts. For
Cisco ASA, you can also define or discover any modules that are installed in the appliance.
To be monitored by MARS, the Cisco ASA, PIX 7.0, and FWSM device types have the following
additional requirements:
•
•
Note
The Cisco ASA, PIX 7.0, and FWSM can run in single context mode, which means that the system
context acts as both the admin context and a security context.
To add and configure a Cisco firewall device, follow these steps:
Do one of the following:
Step 1
•
User Guide for Cisco Security MARS Local Controller
4-8
logging message 302007
logging message 302008
logging message 302013
logging message 302014
logging message 302015
logging message 302016
logging message 302017
logging message 302018
logging message 302020
logging message 302021
logging message 302022
logging message 302023
logging message 305009
logging message 609001
logging message 609002
logging message 313001
each context requires a unique routable IP address for sending syslog messages to MARS
each context must have a unique name (hostname+ domain name)
If you are adding an FWSM, you must be on the main page of the Cisco switch to which you are
adding it. On that page, click Add Module.
Chapter 4
Configuring Firewall Devices
78-17020-01
