Processor feeder
trays
Feeder tray
capacity
Operator Guide

Feeder trays

Multiple feeder trays can be configured to feed paper for jobs in
the most effective manner. For example, the trays can provide
nonstop printing of a complex job that requires many paper
stocks, or only a few stocks, by using the trays continuous
loading capability. A different input tray can also be selected for
each copy of a specific page in a print job, for example, to
provide different paper colors for specific pages.
The printing system may have up to six feeder trays: two
processor feeder trays and two to four high-capacity trays. Four
addressable input trays are standard with the system, and two
additional high-capacity trays are optional.
Two processor feeder trays (trays 1 and 2) are located in the
main part of the printer and are not part of a feeder/stacker
module.
Trays 1 and 2 can handle paper sized from 8 by 10 inches / 203
by 254 mm to 9.02 by 14.02 inches / 230 by 356 mm.
The feeder trays have the following capacities, based on 20
pound or 80 gsm (grams per square meter) paper:
• Tray 1: 1100 sheets
• Tray 2: 600 sheets
• Trays 3, 4, 5, and 6 (high-capacity trays): 2600 sheets
each
An elevator moves each tray up or down when it is in use. In
each tray, a control panel consisting of a button, indicators, and
paper level displays controls the elevator tray and indicates its
status.
Overview
1-21
