Figure A-1: Mounting Power Supplies
Plug into upper-most
connector on CPU
Figure A-2: Connecting the CPU Row Ribbon Cable
80
Mount the Main Power Supply
here with the screws provided.
CPU Row Ribbon
S5000 15583 Rev.
Mount the Transformer
here with nuts and lockwashers
provided.
6/10/96 P/N 15583:
Mount the AVPS-24
Audio Visual Power
Supply here with nuts
and lockwashers
provided.
