Pittway NOTIFIER The SYSTEM 5000 Installation Manual page 67

All-Call
(General
Evacuation)
All-Call
Telephone
Page
Telephone
Page
Presignal
Inhibit
MODULE
Remote Command Input Connections
Notes:
1. Initiating Command Circuits are supervised, power limited, and may be connected to limited-energy cable.
2. Maximum line resistance allowed due to wiring is 100 ohms.
B+ B- B+ B- B+ B- B+ B-
16 15 14 13 12 11 10 9
+ - + - + - + -
A B C
TYPE
LAMPS
SWITCH
S5000 15583 Rev.
B+ B- B+ B- B+ B- B+ B-
8 7 6 5 4 3 2 1
+ - + - + - + -
D E F G
MODULE
TYPE
LAMPS
SWITCH
6/10/96 P/N 15583:
Emergency
Alert
Acknowl-
edge
Signal
Silence
Reset
H
67
