Pittway NOTIFIER The SYSTEM 5000 Installation Manual page 56

Trouble
(+) 27.6 VDC
Figure 6-3A: Connection of a 911A Digital Communicator
*For Supervisory contacts, program the initiating zone(s) and map the output to the supervisory contacts. Set Zone 2/3 in DACT for Mode 3.
56
Alarm
CPU
Common
(+) 24 VDC
MPS-24A
S5000 15583 Rev.
Note: Wiring between the FACP
and 911A must be in conduit.
CPU
TB1-14
Alarm
normally open
contacts
TB1-15
TB1-9
Trouble
normally open
contacts TB1-11
+24 VDC
Common
+27.6 VDC
6/10/96 P/N 15583:
911A
911A MPS
6 and 7
8 and 9
10
11
2 TB3-3
4 TB3-4
1 TB2-1
