CHS-4 Chassis
For the mounting of up to four System 5000
modules or AVPS-24 Audio-Visual Power
Supplies. Occupies one cabinet row.
Main Bell Power Harness
(71093)
Power Ribbon
(71085)
Power Harness
(71086)
First-Row Ribbon Cable
(71087)
10
The BE-5000 Basic Equipment Package
CPU-5000 Central Processor Module
This module is the heart of the System 5000. It controls and monitors the system
modules and provides a full accounting of system status. In addition, the CPU
contains two Notification Appliance Circuits, a Remote Signaling Municipal Tie
Circuit, and Form-C alarm and trouble contacts. Field programming of the system
is accomplished from this module via the use of the Programming Key. Slide-In
labels for programming, control, and system operation are provided with the CPU,
as well as End-of-Line and Dummy Load resistors.
CPU Programming Key
Dummy Load Resistor
4.7K, 1/2 watt (71245)
End-of-Line Resistor
4.7K, 1/2 watt (71252)
S5000 15583 Rev.
VP-1 Vented Dress Panel
Covers the top row of modules in the System 5000.
BP-3 Battery Dress Panel
Covers the MPS and the batteries in the System 5000.
KEY #___ PWD#___
6/10/96 P/N 15583:
CPU Slide-in Labels
