RESUME ~~ If for some reason you have interrupted the
CO-OP 41 in the middle of printing points from the
random point file, you may select this option and begin
printing points from where you left off. When selected
the CO-OP 41 will prompt for the point number to resume
printing at.
[RESUME PT?
RESET
Name: Reset Plotter
Purpose: Resets the plotter
Keystrokes:
Operation: RESET can be used to reset the plotter, this is
useful if you ever abort in the middle of another plotting
function and the plotter then does strange things
whenever you execute any of the other plotting functions.
When executed, RESET does the following.
1) Puts the pen in the up position
2) Sets display to FIX 4 (display 4 decimal places)
3) Puts text to horizontal orientation
4) Sets the line type to zero
5) Sets the character size to 12
6) Puts the plotter in the command mode (out
of text mode)
78 CO-OP 41 Data Collector
