NORTH ARROW
Name: North Arrow
Purpose: Draws a north arrow at the current pen position.
Keystrokes: [SHIFT] [NORTH ARROW]
Entry Conditions: None
Operation: When executed the CO-OP 41 will promptif
you really want to plot the north arrow.
[R/S N ARROW |
Press the key if you want the north arrow drawn,if
you hit the key accidently then ignore the prompt and
execute another function.
OPT
Name: Options
Purpose: Allows you to change various plotting options.
Keystrokes:
Entry Conditions: None
Operation: When this function is executed the CO-OP 41
will prompt for the pen to use during plotting.
[PEN NO.?
If you have a single pen plotter then ignore this prompt
and press [R/S], otherwise key in the pen number that you
want to use for this plotting session. Next, the CO-OP 41
66 CO-OP 41 Data Collector
