Additional functions in the plotter module:
LOADR Load random points from a mass memory device. P. 1
LOADT Load text file from a mass memory device. P. 1
SAVER Save random points to a mass memory device. P. 2
SAVET Save text file to a mass memory device. P. 2
Note: These functions are only in plotter module version 2.20
and higher.
LOADR
Purpose: Read random points from a file in the mass memory device
(disc/cassette) into HP41's memory (registers).
Keystrokes: [XEQ] [ALPHA] LOADR [ALPHA]
Operation: First connect the HPIL disc or cassette drive to the
data collector with a pair of HPIL cables.
When this function is executed, the CO-OP 41 prompts for the file
name that contains the random points.
"RDM FILE?"
Enter the file name and press [R/S]. The CO-OP 41 will search
the disc or the cassette tape for this file. If the file exist,
the CO-OP 41 will load the points 1nto tne HP41°'s memory. They
will replace the current random points.
Remark: The random points are not loaded into a file in the data
collector's memory nor the 41's extended memory. If you want to
copy a random points file from a mass memory device into the data
collector's memory, you need to do it in two steps. First you
execute the "LOADR" function to load the random points from a
mass memory device into the 41's memory, then you execute the
"SRDM" function to save them to a file in the data collector's
memory .
LOADT
Purpose: Copy a text file from a mass memory device
(disc/cassette) into HP41l's extended memory.
Keystrokes: [XEQ] [ALPHA] LOADT [ALPHA]
Operation: First connect the HPIL disc or cassette drive to the
data collector with a pair of HPIL cables.
When this function is executed, the CO-OP 41 prompts for the name
of the text file in the mass memory device.
"TEXT NAME?"
