The CO-OP 41 will then prompt for the distance to move
along the specified line.
[DIST?
AZ? If you want the plotter pen to move along a certain
azimuth then key in the azimuth. The CO-OP 41 will
then prompt for the distance (in current scale feet) to
move the pen along this azimuth.
|DIST? |
DEFZ? If you want to move the pen at a deflection angle
to a previously drawn line then you can key in the
deflection angle, the CO-OP 41 will then prompt for the
distance (in current scale feet) to move the pen along the
line defined by the deflection angle.
[DIST?
Remarks: To use the deflection angle DEFZ, you must
have just prior to this used the draw function to draw a
line to take the deflection angle from. If you have not
done this then you can specify a line to take the deflection
from by setting up the back sight (BACKS function) along
the line that you want to take the deflection angle from.
E
Name: Pen East
Purpose: Moves the plotter pen to the east on the plat.
Keystrokes: (E]
Entry Conditions: None
Plotter Module User's Manual 53
