Chapter 2
The Fundamentals
In this chapter and for the rest of the tutorial section, we
will go back to working with the FIRST job that was
presented in the Surveying Module User's Manual. If you
have not entered this into the CO-OP 41 Data Collector,
you can either go back to the Surveying Module User's
Manual, or consult Appendix A The FIRST Job in this
manual for the required keystrokes.
OLDJOB [JOB NAME? :
FIRST
[RAWDAT OFF
~ |
It is assumed that you have already executed the plotter
initialization function. If you haven't, then do so now.
THE FAST PLOT FUNCTIONS
Generally, the plotting functions operate as follows:
If you are plotting points, then the function will
either plot all of the points, or allow you to specify
a series of points to plot, or plot the points
contained in the random point file.
* If you are plotting lines, then the function will plot
lines between the point numbers stored in the
random point file.
