Removing Bezel Blanks

2-4 Upgrading the Compaq Deskpro EP Series
1. Shut down the operating system properly, then turn off the
computer and any external devices. Disconnect the power
cord from the power outlet and disconnect any external
devices.
2. Remove the computer access panel.
3. Remove the front bezel.
4. Gently pull the subpanel, with the bezel blanks secured in
it, away from the front bezel, then remove the desired bezel
blank.
CAUTION:
Hold the subpanel straight when you pull it away from
the front bezel. Pulling the subpanel away at an angle could
damage the pins that align it within the front bezel.
Removing Bezel Blanks from the Subpanel (Desktop Shown)
When replacing the subpanel, ensure that the aligning
pins and any remaining bezel blanks are in their proper
orientation.
