Removing Bezel Blanks

2-4 Hardware Upgrades
1. Shut down the operating system properly, then turn off the
computer and any external devices. Disconnect the power cord
from the power outlet and disconnect any external devices.
2. Remove the computer access panel.
3. Remove the front bezel.
4. Gently pull the subpanel, with the bezel blanks secured in it, away
from the front bezel, then remove the desired bezel blank.
CAUTION: Hold the subpanel straight when you pull it away from the
front bezel. Pulling the subpanel away at an angle could damage the
pins that align it within the front bezel.
Removing Bezel Blanks from the Subpanel (Desktop Shown)


When replacing the subpanel, ensure that the aligning pins and
any remaining bezel blanks are in their proper orientation.
