Port
7000
7100
NOTE: mDNS/Multicast must be enabled on the network in order for Apple Screen Mirroring
7236
7250
8554
8554
60000
1000‑
65384
1000‑
65384
19302
22022
22023
29053
50000
60000
Toolbelt
The Extron Toolbelt utility is available on the Extron website. Toolbelt is a stand‑alone Windows application for
the management of control systems. Toolbelt can automatically discover ShareLink Pro devices on a network
(see the Toolbelt Help file). You also can manually add devices, using the known IP addresses. Once you log in
to a ShareLink Pro device, you can perform tasks such as:
•
View the device and system information.
• View and edit network information.
Type Direction
TCP Both
TCP Both
and Miracast to function properly.
TCP Both
TCP Both
554 RTSP Both
RTSP Both
RTSP Both
RTP Both
UDP Outbound
UDP Outbound
UDP Both
TCP Both
TCP Inbound
TCP Both
RTP Both
RTP Both
Function Open
Apple Screen
Required
Mirroring
Apple Screen
Required
Mirroring
Miracast Required
Miracast Required
Active Learning Required
ConferenceShare Required
ConferenceShare Required
ConferenceShare Required
Video streaming Required
Audio streaming Required
WebShare Required
Internal storage
Required
access
Control Required
Apple Screen
Required
Mirroring
Active Learning Required
ConferenceShare Required
ShareLink Pro 2500 • Reference Information
Notes
This port is used for Apple Screen
Mirroring. If this is not available, then it
uses the next available port (e.g., 7001,
7002, and so on).
This port is used for Apple Screen
Mirroring. If this is not available, then it
uses the next available port (e.g., 7101,
7102, and so on).
This port is used for Miracast, for
both Wi‑Fi Direct and Miracast‑over‑
Infrastructure, in order to establish and
manage Miracast sessions between the
client device and the Sharelink Pro.
This is the port on which the ShareLink
Pro listens for Miracast packets when
Miracast over Infrastructure is enabled.
This port is used for Active Learning.
This port is used for ConferenceShare
This port is used for ConferenceShare.
This port is used for ConferenceShare
These ports are used for streaming
video data to the ShareLink Pro.
Port is negotiated at run‑time in the
range 1000 to 65384 (randomly).
These ports are used for streaming
audio data to the ShareLink Pro.
Port is negotiated at run‑time in the
range 1000 to 65384 (randomly).
This port is used for WebShare
This port is used by PCS to access the
internal file storage of the ShareLink Pro.
This port is used for controlling the
ShareLink Pro via SIS‑over‑SSH.
This port is used for Apple Screen
Mirroring.
This port + the next 99 consecutive ports
are used for Active Learning.
This port + the next 99 consecutive ports
are used for ConferenceShare.
