6. Click on the LAN B tab (see
NOTE: LAN B is chosen because
it is the LAN port connected to
PRIVATE Subnet #1.
7. Click the Enable checkbox (
advertisement functionality on LAN B.
8. Select the appropriate LAN port (
Pro device in every other subnet (excluding Subnet #1)
on the PRIVATE NETWORK. The appropriate LAN port is
the port on the ShareLink Pro device that connects it to
the PRIVATE NETWORK via its own subnet.
9. Click the Advertise AirPlay enable/disable slider switch for
SLP-Huddle-1 ( ).
1
at right).
2
) to enable AirPlay
3
) for each ShareLink
4
ShareLink Pro 2500 • Enterprise Discovery Service
