ShareLink Pro 2500 • Setup Guide
This guide provides instructions for installing and connecting the Extron ShareLink Pro 2500 4K wireless presentation system. The
ShareLink Pro 2500 allows anyone to present wireless or wired content from a personal device—such as a PC, laptop,
smartphone, or tablet—onto a display. It is compatible with Windows
iOS smartphones and tablets.
IMPORTANT NOTE:
Go to www.extron.com
before connecting the product to the power source.
Installation
Mounting
The ShareLink Pro 2500 can be placed on a desktop or tabletop using the included rubber feet, or mounted to a rack or furniture
(see the ShareLink Pro 2500 User Guide, available at www.extron.com, for mounting options and instructions).
NOTE:
Do not block or restrict air ventilation holes on the top and sides of the ShareLink Pro 2500.
Rear Panel Features and Cabling
INPUT
POWER
12V 1
--A MAX
HDMI HDMI/CEC
A A B B
Figure 1. ShareLink Pro 2500 Rear Panel
Power input — Connect a power supply to this 2-pole captive screw connector.
A
HDMI input — Connect an HDMI source device to this input.
B
HDMI outputs — Connect HDMI displays to these female HDMI connectors. These independent HDMI outputs (primary and
C
secondary) can be mirrored or matrixed (allowing different content to be routed to each output). Output 1 must be connected
to a display before Output 2 can be used. Output 2 can be disabled using Product Configuration Software (PCS) or SIS
commands.
Audio input — Connect a microphone for ConferenceShare to this 5-pole, 3.5 mm captive screw connector. This input can
D
be mixed with the audio output signal using PCS or SIS commands. See Figure 2 for unbalanced or balanced input wiring.
Audio output — Connect a balanced or unbalanced stereo (or dual mono) line level audio device to this 5-pole 3.5 mm
E
captive screw connector. Wire the connector as shown in figure 2:
:
ATTENTION
• For unbalanced audio, connect the sleeves to the ground contact. DO NOT connect the sleeves to the negative (–)
contacts.
• Pour l'audio asymétrique, connectez les manchons au contact au sol. Ne PAS connecter les manchons aux contacts
négatifs (–).
Tip
Sleeve
Tip
Sleeve
Unbalanced Input
Figure 2. Audio Captive Screw Connector Wiring
COM port — Connect an RS-232 controllable device to this 3-pole captive screw connector (see the ShareLink Pro 2500 User
F
Guide for details).
for the complete user guide, installation instructions, and specifications
OUTPUT AUDIO
2
LINE IN LINE OUT
L R L
HDMI/CEC
C C D D E E
Tip
Left
Ring
Sleeve(s)
Right Tip
Ring
Balanced Input or Output
and macOS
®
COM IR/S DIG I/O
RESET
R
A/PoE +
Tx Rx G S G 1 2 G
F F G G H H I I
Tip
Left
NO Ground Here
Sleeve(s)
Tip
Right
NO Ground Here
Unbalanced Output
computers, as well as Android
®
B
J J
Left
Right
Do not tin the wires!
and Apple
