Other Configuration Options
This section covers the following configuration options for the ShareLink Pro:
•
Device Discovery using ShareNext™
•
Digital Signage Feature
• Miracast Connection Using the WFA 100
Device Discovery using ShareNext
ShareNext uses Bluetooth technology to discover nearby ShareLink Pro devices equipped with a
WFA 100. This is useful in applications where client devices and ShareLink Pro devices are in
separate subnets within a network. Client devices discover the ShareLink Pro via Bluetooth, but they
will still connect to the ShareLink Pro over the network. It is imperative that client devices have
Bluetooth enabled and have a routable network path to the ShareLink Pro.
Display Display
HDMI
Extron
ShareLink Pro 2500
POWER
12V
--A MAX
ShareNext works with client devices using ShareLink Pro software (Windows, macOS, iOS, and
Android) as well as Apple devices (macOS and iOS) that support native screen mirroring (AirPlay).
NOTE:
• ShareLink Pro devices must be equipped with the WFA 100 adapter in order for ShareNext to
be enabled.
• The client devices must be able to access the ShareLink Pro over the network to discover it.
WFA 100
HDMI INPUT INPUT OUTPUT USB
HDMI DECODER SS 5G
1 2
900mA 900mA
SIGNAL HD WIN HD PASS
CONFIG
STANDBY
WINDOW PASS-THROUGH HDCP DECODER
SCREEN
ShareLink Pro 2500
INPUT OUTPUT AUDIO COM IR/S DIG I/O
1 2
LINE IN LINE OUT
L R L R RESET
HDMI HDMI/CEC HDMI/CEC Tx Rx G S G 1 2 G A/PoE+
Ethernet
Private
Regional Sales Regional Sales
150 SOUTH
WEST
120
EAST
NORTH
90
60
30
0
Phone
Regional Sales Regional Sales
150
SOUTH
WEST
120
EAST
NORTH
90
60
30
0
B
Laptop
Network
Public
ShareLink Pro 2500 • Other Configuration Options
CORPORATE NETWORK
Facility/Room
Wireless Access Point
Ethernet
