Specifications — PMP Series
General
Maximum load capacity ............... 200 lbs
Material .......................................... Steel
Pipe diameter ................................. 1.5" (3.8 mm) o.d., 11.5 NPT threads
Pipe lengths ("A" in the above illustration)
PMP 2 .................................. 2.0" (51 mm)
PMP 4 .................................. 4.0" (102 mm)
PMP 6 .................................. 6.0" (152 mm)
PMP 10 ................................ 10.0" (254 mm)
PMP 12 ................................ 12.0" (305 mm)
PMP 18 ................................ 18.0" (457 mm)
PMP 24 ................................ 24.0" (610 mm)

Product weights

PMP 2 .................................. 0.3 lbs (0.1 kg)
PMP 4 .................................. 0.7 lbs (0.3 kg)
PMP 6 .................................. 1.0 lbs (0.5 kg)
PMP 10 ................................ 2.1 lbs (0.9 kg)
PMP 12 ................................ 2.3 lbs (1.0 kg)
PMP 18 ................................ 3.6 lbs (1.6 kg)
PMP 24 ................................ 4.6 lbs (2.1 kg)

Shipping weights

PMP 2 .................................. 1 lb (1 kg)
PMP 4 .................................. 1 lb (1 kg)
PMP 6 .................................. 2 lbs (1 kg)
PMP 10 ................................ 3 lbs (2 kg)
PMP 12 ................................ 3 lbs (2 kg)
PMP 18 ................................ 5 lbs (2 kg)
PMP 24 ................................ 6 lbs (3 kg)
Vibration ........................................ ISTA 1A in carton (International Safe Transit Association)
Listings............................................ UL, CUL
Compliances ................................... CE
Warranty ........................................ 3 years parts and labor
N Specifications are subject to change without notice.
A-2 Extron PMP Series Projector Mounting Poles • Specifications
A
1.75"
1.6"
(44.5 mm)
(41.3 mm)
1.6"
(40.6 mm)
(Ø 1.9") OD
(1 1/2" - 11.5 NPT - 2A)
(Ø 1.7") ID
(7.53-101907-D2)
