To load a design from a FAT16 or FAT32 formatted flash disk or external hard drive, press File and
then select Udisk and Copy to Memory. Select the design in the File menu and then select Run.
Various parameters can be adjusted using the console's menus and submenus, including setting
multiple origin points to engrave the same design on your material up to eight times in a single
session.
When running a design from the control console, this will be the main display. The design should
appear in the top left corner and its name and the current speed and power settings on the top
right. The position of the primary laser head relative to the workbed appears as the X (horizontal)
and Y (vertical) coordinates. The Z coordinate shows the elevation of the workbed itself. The U
coordinate can be configured to control rotary axes or an automatic feed if either is installed. Below
them are the layers with notes about their separate speeds in mm/s and their maximum power
relative to your machine's rated power. The batch count on the lower left keeps track of the number
of times the current design has been engraved in a single session. Press St/Pau to start engraving
your loaded pattern and pause engraving when needed.
If there is ever an emergency situation such as a fire, do not use the control panel
to pause or stop the engraving. Hit the emergency stop button immediately.
