Omtech SH-G1390 User Manual page 25

A Left Top Access Door
B Pass-Through Doors
Left Bottom Access Door
C
D Right Top Access Door
E Right Bottom Access Door
F Caster Wheels
G Feet
This door provides access to the main bay for work on the mirror and Y-axis rail.
These doors open to allow larger pieces of material to be fed through the workbed.
Additional care must be taken to avoid seeing or suffering exposure to the laser beam
and its reflection.
This door provides access to the laser power supply.
This door provides access to the cable carrier, motor, etc.
This door provides access to the mainboard, motor drivers, and power supplies.
The front wheels include locks to hold the engraver in place.
These feet can be rotated down to help anchor the machine in place.
18
