A Graphic Display Area
B Running Parameters
C Coordinates
D File Dimension
E Layer Parameters
F Net Status
Key Lock Status
G
H Running Status
I Working Number
J Progress Bar
Traces the processed file image during file preview display and
processing.
Displays the file number, speed, and maximum power of the
current processing file.
Displays the coordinate value of the current position of the laser
head.
Displays the dimension of the current file.
Displays the layer parameters of the current processing file or
the layer parameters of the preview file. The parameters from
left to right are: layer, color, layer speed, and layer maximum
power.
Displays the status of connection to the Internet. When network
connection is successful,
displayed.
When the keyboard lock function is enabled,
and input will not be accepted. Pressing a key will prompt
a request for the password. Enter the correct password to
reactivate the keypad.
Displays the current working status of the system, which are: idle,
paused, completed, or running. The working time is displayed on
the right.
Displays the processed quantity of the current processing file.
Displays the status of the current engraving process.
24
is displayed. Otherwise,
is displayed,
is
