Power Button
Robot Stick Enable Indicator
Hardware Installation Manual: TM25S/TM30S series Hardware version: 5.02
TECHMAN ROBOT INC.
5F., No. 58-2, Huaya 2nd Rd., Guishan Dist., Taoyuan City, 333411 , Taiwan
Speed Indicator
Play Button
- Button
Emergency Stop Button
Figure 30: Robot Stick (front)
Figure 31: Robot Stick (back)
Reset Button
MODE Indicator
M/A Button
Pause Button
Stop Button
+ Button
Enabling Switch
