Retain all shipping containers and packaging materials. These items may be necessary to settle claims or
at a later date, to relocate equipment.

6.3 Unboxing

6.3.1 Carton Types

The TM AI Cobot product comes with 2 cartons: the robot arm carton, and the control box carton, as shown
below. Also, a SEMI Emergency OFF switch carton will comes along with the SEMI series. For TM25S-M
SEMI and TM30S-M SEMI, there will be an additional carton comes with the SEMI Emergency OFF Box.
Refer below for the ratio of the cartons. The actual sizes of the cartons may differ from measurements.

Figure 72: Robot Arm Carton (1/2)

6.3.2 Contents of Each Carton

Each carton has the following contents. Check them when you unpack the cartons for the first time. If any
Hardware Installation Manual: TM25S/TM30S series Hardware version: 5.02
TECHMAN ROBOT INC.
5F., No. 58-2, Huaya 2nd Rd., Guishan Dist., Taoyuan City, 333411 , Taiwan

Figure 74: Control Box Carton (AC, DC, and DC SEMI)

Figure 73: Robot Arm Carton (2/2)
