Figure 15: Top View of TM30S / TM30S-M / TM30S-X Movement Range Diagram

4.2.1.4 Payload and Torque

The maximum allowed payload of the robot arm is related to its center of gravity offset, which is defined
as the distance from the center point of the robot end of the flange to the payload's center of gravity.
The following figure shows the relationship between payload and the center of gravity offset:
