Anybus
Tunnel Gateway
8.2. Reboot Using the Reset Button
Before You Begin
NOTE
Pressing and holding the reset button for more than 10 seconds will initiate a factory reset of the
Tunnel Gateway.
During reboot, the Tunnel Gateway is temporarily unavailable for approximately two minutes.
Procedure
1.
Ensure that the Tunnel Gateway is powered on.
Figure 34. Power on the Tunnel Gateway
2.
Use a pointed object, such as a paper clip to quickly press and release the Reset button.
Figure 35. Quickly press and release the Reset button
3.
Wait while the Tunnel Gateway reboots.
Result
You are logged out of the Tunnel Gateway built-in web interface and redirected to the login page.
Page 38 of 45
Reboot Using the Reset Button
SCM-1202-233 Version 1.0
