4.2. Connect to 5G Core (5GC) Network
Figure 2. Ethernet port, WAN
Connect your 5G core network, N6 or NAT router to the Tunnel Gateway WAN port.
Ethernet RJ45 Connector Pinout
Ethernet RJ45 Connector
Page 6 of 45
Pin
1
2
3
4
5
6
7
8
Connect to 5G Core (5GC) Network
Description
TD+
TD-
RD+
Not used
Not used
RD-
Not used
Not used
SCM-1202-233 Version 1.0
