Technical Data

9. Technical Data
For complete technical specifications and regulatory compliance information, please visit
www.hms-networks.com.

9.1. Technical Specification

Article identification AWB5300
Ethernet connector Ethernet 100 Mbps x 5
Power connector 24 VDC, BL 3.50/03 connector +-15%
Power supply 24 V (9 - 32 VDC), 1.5 A Power Supply
The power supply must be a regulated limited power source (LPS) according to IEC/EN 62368-1, Annex Q, or IEC/EN
60950-1, clause 2.5
Current consumption Maximum: 0.4 A
Storage temperature -20 to +60 °C (IEC 60068-2-1 and IEC 60068-2-2)
Operating temperature 0 to +55 °C (IEC 60068-2-1 and IEC 60068-2-2)
Humidity 5–85 % RH, non-condensing (IEC 60068-2-30)
Housing material Continuously hot-dip aluminium-zinc coated steel
Protection class IP20, NEMA rating 1
Product weight 400 g
Dimensions 79 x 107 x 65 mm (W x H x D)
Mounting DIN rail (EN 50022)
Network shield conductance via DIN rail
SCM-1202-233 Version 1.0
®
Anybus Tunnel Gateway
Page 45 of 45
