Troubleshooting
8. Troubleshooting
8.1. Diagnostics
8.1.1. Event Log
Figure 33. Event log page example
To export the log data, click Export. An Excel XLSX file with the data is downloaded to your PC.
How To Analyze the Information
The log follows the FIFO principle, first in and first out. The oldest (first) value is processed first.
Value
Time (d:hh:mm:ss.ms)
Message
Type
SCM-1202-233 Version 1.0
Description
The date and time when the event occurred.
A brief description of the event.
The severity of the event occurred.
For description of the symbols, see
Status Symbols (page
®
Anybus
Tunnel Gateway
24).
Page 37 of 45
