Anybus Tunnel Gateway

5.7. Local Ethernet Settings

Configure the IP settings for the Ethernet device(s) connected to the Tunnel Gateway via an Ethernet cable. See
also Connect Ethernet Devices (page
Figure 18. Local Ethernet settings
Table 2. Local Ethernet IP settings
Setting Value
IP address There is no default IP address.
Subnet mask 255.255.255.0, default value
Gateway address There is no default Gateway address.
0.0.0.0, default value
Page 22 of 45
7).
Description
Enter the network IP address.
Write in IPv4 dot-decimal notation.
Enter the network subnet mask.
Write in IPv4 dot-decimal notation.
Enter the network gateway address.
Write in IPv4 dot-decimal notation.
If there is no network gateway address available, enter 0.0.0.0.
Local Ethernet Settings
SCM-1202-233 Version 1.0
