WAN Settings

5.6. WAN Settings
On the WAN page, configure the IP settings for the 5G core network that the Tunnel Gateway is connected to.
See also Connect to 5G Core (5GC) Network (page
Figure 17. WAN settings
Table 1. WAN IP settings
Setting Value
IP address There is no default IP address.
Subnet mask 255.255.255.0, default value
Gateway address There is no default Gateway address.
0.0.0.0, default value
SCM-1202-233 Version 1.0
6).
Description
Enter the network IP address.
Write in IPv4 dot-decimal notation.
Enter the network subnet mask.
Write in IPv4 dot-decimal notation.
Enter the network gateway address.
Write in IPv4 dot-decimal notation.
If there is no network gateway address available, enter 0.0.0.0.
®
Anybus Tunnel Gateway
Page 21 of 45
