5. Configuration
5.1. Connect to Configure
5.1.1. Connect to PC and Power
When configuring the Tunnel Gateway it must be connected to a PC.
Figure 6. Connect to PC and power
1.
Connect an Ethernet cable between one of the Tunnel Gateway LAN switch ports and your PC.
2.
Connect the Tunnel Gateway Power connector to a power supply.
SCM-1202-233 Version 1.0
®
Anybus
Tunnel Gateway
Page 11 of 45
