Goodrive880 Series Regenerative Rectifier Unit Hardware Manual
5 Regenerative rectifier control unit (RCU)

5.1 RCU composition

Symbol Component
1
2 Battery cover plate
3 Indicator
4
5 Nameplate
6
7
8 Power interface
Fiber optic
9
interface
202401 (V1.0)
①
②
③
④
⑤
⑥
⑦
⑧
⑨ ⑩
Table 5-1 Function description
Applied to 73.5×103×23.5(mm) function expansion modules and
Slot 1
communication expansion card
Button battery replacement cover. The internal button battery is a
non-rechargeable lithium battery that needs to be replaced regularly.
Power supply, fault, running indicator
Applied to 73.5×103×23.5(mm) function expansion modules,
Slot 2
communication expansion card, and optical fiber expansion card
Nameplate information
Standard microSD memory card, flexible to plug and unplug, capacity:
SD card
32GB
Applied
Slot 3
communication expansion card, and optical fiber expansion card
24V power input terminal
Master/slave fiber optic interface (optional)
⑬ ⑫
⑪ ⑯
Function description
to 73.5×74×23.5(mm)
Regenerative rectifier control unit (RCU)
⑭
⑮
function expansion modules,
45
