Goodrive880 Series Regenerative Rectifier Unit Hardware Manual
Product model
400VAC
GD880-81-0116-4-Z
GD880-81-0149-4-Z
GD880-81-0183-4-Z
GD880-81-0245-4-Z
GD880-81-0299-4-Z
202401 (V1.0)

Appendix D Order No.

Structure Order No.
GD880-81-0116-4
ACR-0116-0M20-0.4SC-4149-RO 1
HC-0110-4-Z
RV-380V
A4+L
GD800-LB
IVDM10
EC-TX821
HFBR-1M
GD880-81-0149-4
ACR-0149-0M20-0.4SC-4149-RO 1
HC-0110-4-Z
RV-380V
A4+L
GD800-LB
IVDM10
EC-TX821
HFBR-1M
GD880-81-0183-4
ACR-0183-0M15-0.4SC-4149-RO 1
HC-0110-4-Z
RV-380V
A4+L
GD800-LB
IVDM10
EC-TX821
HFBR-1M
GD880-81-0245-4
ACR-0245-0M12-0.4SC-4149-RO 1
HC-0110-4-Z
RV-380V
GD800-LB
A6+L
SOP-880-01
L=2M (CHV-SE)
IVDM10
EC-TX821
HFBR-1M
GD880-81-0299-4
ACR-0299-090U-0.4SC-4149-RO 1
HC-0200-4
RV-380V
A6+L
GD800-LB
SOP-880-01
L=2M (CHV-SE)
IVDM10
Qty Remarks
1 Rectifier module
Filter reactor
1 Precharge component
1 Surge protection module
1 EMI filter module
1 AC voltage detection module
1 Optical fiber expansion module
1 1m optical fiber
1 Rectifier module
Filter reactor
1 Precharge component
1 Surge protection module
1 EMI filter module
1 AC voltage detection module
1 Optical fiber expansion module
1 1m optical fiber
1 Rectifier module
Filter reactor
1 Precharge component
1 Surge protection module
1 EMI filter module
1 AC voltage detection module
1 Optical fiber expansion module
1 1m optical fiber
1 Rectifier module
Filter reactor
1 Precharge component
1 Surge protection module
1 EMI filter module
1 Keypad
1 2M keypad cable
1 AC voltage detection module
1 Optical fiber expansion module
1 1m optical fiber
1 Rectifier unit
Filter reactor
1 Precharge component
1 Surge protection module
1 EMI filter module
1 Keypad
1 2M keypad cable
1 AC voltage detection module
