Goodrive880 Series Regenerative Rectifier Unit Hardware Manual
Figure 3-17 shows the 850mm-wide cabinet installation for L+2*A8.
Figure 3-17 Installation diagram of L+2*A8 in an 850mm-wide cabinet
①
④
⑤
⑥
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
Note: A 40X40 sealing sponge must be used at the position corresponding to the air baffle in the
front/back door panel, which prevents air duct reflow.
202401 (V1.0)
②
③
⑦
⑧
Unit-top copper bar assembly
Left protective plate
Back sealing sponge
Unit-top fixing assembly
Unit bottom fixed plate
Front sealing sponge
Power supply board
L1-phase copper busbar
L2-phase copper busbar
L3-phase copper busbar
Copper busbar of (+)
Copper busbar of (-)
Busbar clamp support
Right protective plate
⑮ ⑯
⑩
⑬
⑫
⑪
⑨
Name
AC fuse
DC fuse
Cabinet
Busbar clamp
Mechanical installation
⑱
⑭
⑰
