INVT Goodrive880 Series Hardware Manual page 94

Goodrive880 Series Regenerative Rectifier Unit Hardware Manual
Product model
GD880-81-5310-4-Z 2*(2*A8+L)
690VAC
GD880-81-0600-6-Z
GD880-81-0900-6-Z
GD880-81-1180-6-Z
202401 (V1.0)
Structure Order No.
EC-TX821
HFBR-1M
GD880-RCU-16
GD880-81-0900-4
GD880-04-1770-4
2*A8+L-K
BUB800-1770-4
HFBR-5M
SOP-880-01
L=2M (CHV-SE)
IVDM10
EC-TX821
HFBR-1M
GD880-RCU-11
GD880-81-0600-6
GD880-04-0600-6
A8+L-K
BUB800-0900-6
A8+L HFBR-3M
SOP-880-01
L=2M (CHV-SE)
IVDM10
EC-TX821
HFBR-1M
GD880-RCU-11
GD880-81-0900-6
GD880-04-0900-6
A8+L-K
BUB800-0900-6
A8+L HFBR-3M
SOP-880-01
L=2M (CHV-SE)
IVDM10
EC-TX821
HFBR-1M
GD880-RCU-13
GD880-81-0600-6
GD880-04-1180-6
2*A8+L-K
BUB800-1770-6
2*A8+L HFBR-3M
SOP-880-01
L=2M (CHV-SE)
IVDM10
EC-TX821
HFBR-1M
Qty Remarks
1 Optical fiber expansion module
1 1m optical fiber
1 Control module
6 Rectifier unit
3 Filter module
3 Fast connector kit (for -K models)
3 Precharge component
6 3M fiber optic
1 Keypad
1 2M keypad cable
1 AC voltage detection module
1 Optical fiber expansion module
1 1m optical fiber
1 Control module
1 Rectifier unit
1 Filter module
1 Fast connector kit (for -K models)
1 Precharge component
1 3M fiber optic
1 Keypad
1 2M keypad cable
1 AC voltage detection module
1 Optical fiber expansion module
1 1m optical fiber
1 Control module
1 Rectifier unit
1 Filter module
1 Fast connector kit (for -K models)
1 Precharge component
1 3M fiber optic
1 Keypad
1 2M keypad cable
1 AC voltage detection module
1 Optical fiber expansion module
1 1m optical fiber
1 Control module
2 Rectifier unit
1 Filter module
1 Fast connector kit (for -K models)
1 Precharge component
2 3M fiber optic
1 Keypad
1 2M keypad cable
1 AC voltage detection module
1 Optical fiber expansion module
1 1m optical fiber
Order No.
88
