Note: A 40X40 sealing sponge must be used at the position corresponding to the air baffle in the
front/back door panel, which prevents air duct reflow.
3.3.6.3 Layout and mounting for L+2*A8
Figure 3-16 shows the 850mm-wide cabinet layout for L+2*A8.
No.
1
2
3
4
5
202401 (V1.0)
Power supply board
L1-phase copper busbar
L2-phase copper busbar
L3-phase copper busbar
Busbar fixing clamp
Copper busbar of (+)
Copper busbar of (-)
Right protective plate
Busbar clamp support
Figure 3-16 Cabinet layout for L+2*A8
Regenerative rectifier unit
Regenerative rectifier filter unit
Regenerative rectifier unit
Name
Name
DC fuse
AC fuse
Mechanical installation
①
②
③
④
⑤
