INVT Goodrive880 Series Hardware Manual page 80

Goodrive880 Series Regenerative Rectifier Unit Hardware Manual
Figure B-5 Installation dimensions of A8 unit fast connector (unit: mm)
215
65
70 65
70 70
Dimensions of fast
connector female end
202401 (V1.0)
Fast connector
female end
200
70
8-M5
191
Recommended hole positions for
installing and fixing the fast
connector female end
35
22
4-M8
Recommended distance between fast
connector male and female ends
Figure B-6 Layout of 1*A8 frame bottom support
70 70
（Side fixing hole)
3- 17
2-M8
35
248
6- 9.0
110
210
Fast connector
male end
Male end
Female end
fixing side
fixing side
15
33
4-M6
Dimension drawings
33 447
461
586.5
74
