Manage Trace Files

Copy trace files to and from an external storage device (thumbdrive, PC, etc),
and delete traces.

Screen Image

Figure 23 Example, Screen Image

Quick Save Screen

Saves the current trace with a standard naming convention.
Note: Files are saved in .bmp format with the naming convention of
"ScreenDDHHMMSS.bmp".

Full Screen

Enlarges the graph area to the size of the whole screen. Press escape to go back
to regular screen.

Print Screen Image

Prints the current screen image and presents print setting options for print
adjustment.
Figure 24 Print Screen Menu
38
