INSTRUCTION BOOK
OPERATING INSTRUCTIONS
®
TERMLINE
LOAD RESISTOR
MODELS 8141 & 8141-010
Electronic Corporation
Cleveland (Solon) Ohio USA
© Copyright 1998 by Bird Electronic Corporation
Instruction Book Part Number 920-8141 Rev. D
®
Termaline
is a Registered Trademark
of Bird Electronic Corporation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TERMLINE 8141 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for BIRD TERMLINE 8141

  • Page 1 OPERATING INSTRUCTIONS ® TERMLINE LOAD RESISTOR MODELS 8141 & 8141-010 Electronic Corporation Cleveland (Solon) Ohio USA © Copyright 1998 by Bird Electronic Corporation Instruction Book Part Number 920-8141 Rev. D ® Termaline is a Registered Trademark of Bird Electronic Corporation...
  • Page 2: Safety Precautions

    Safety Precautions The following are general safety precautions that are not necessarily related to any specific part or procedure and do not necessarily appear elsewhere in this publication. Keep Away From Live Circuits Operating personnel must at all times observe general safety precautions. Do not replace components inside equipment with the high voltage supply turned on.
  • Page 3: Safety Symbols

    This is a potentially toxic ceramic and may be harmful to your health. Beryllia oxide must be disposed of in accordance with the legal statutes dealing with hazardous material. Do not attempt to repair this unit, but return to BIRD ELECTRONIC CORPORATION.
  • Page 4: Caution Statements

    Caution Statements The following equipment cautions appear in the text whenever the equipment is in danger of damage and are repeated here for emphasis. CAUTION Do not operate this equipment over the rated 250 watts continuously. Damage to the resistive element will result. Safety Statements USAGE ANY USE OF THIS INSTRUMENT IN A MANNER NOT...
  • Page 5 SERVICE SERVICING INSTRUCTIONS ARE FOR USE BY SERV- ICE - TRAINED PERSONNEL ONLY. TO AVOID DAN- GEROUS ELECTRIC SHOCK, DO NOT PERFORM ANY SERVICING UNLESS QUALIFIED TO DO SO.
  • Page 6: About This Manual

    About This Manual This instruction book covers the models 8141 and 8141-010 Termaline Load Resistor. This instruction book is arranged so that essential information on safety is contained in the front of the book. Reading the Safety Precautions Section be- fore operating the equipment is strongly advised.
  • Page 7: Table Of Contents

    Table Of Contents Safety Precautions ..... . i Safety Symbols ..... . ii Warning Statements .
  • Page 8 Shutdown ......7 Emergency Shutdown ....8 Maintenance .
  • Page 9: Introduction

    Chapter 1 Introduction This instruction book is intended for use by operators of the General Models 8141 and 8141-010 Termaline Load Resistor. This chapter contains introductory information including product specifications; items supplied; and accessory items. The Models 8141 and 8141-010 Termaline Load Resistor are Purpose And Function portable, general purpose 50 ohm coaxial transmission line...
  • Page 10: Power And Utility Requirements

    VSWR dc-1000 MHz 1.1:1 maximum 1000-18000 MHz 1.2:1 maximum 1800-2500 MHz 1.3:1 maximum Connectors Bird Quick Change “QC” Female N Normally supplied. Power Range 250 W continuous, 300 W intermittent (10 Minutes maximum). Frequency Range dc to 2500 MHz Dimensions 9-9/16”L x 5-15/16”W x 8-1/2”H...
  • Page 11: Theory Of Operation

    Chapter 2 Theory Of Operation The Models 8141 and 8141-010 Termaline Load Resistor General consists essentially of a cylindrical film type resistor im- mersed in a dielectric coolant. The resistor, individually se- lected for its accuracy, is enclosed in a special tapered housing which provides a linear reduction in surge imped- ance directly proportional to the distance along the resistor.
  • Page 12: Installation

    Chapter 3 Installation Position the Model 8141 and 8141-010 Termaline Load Re- General sistor to provide at least six inches of unobstructed space around and above the unit. Place the load to permit the shortest possible cable length between the unit and the transmitting equipment.
  • Page 13: Operating Instructions

    Chapter 4 Operating Instructions Connect the Models 8141 and 8141-010 Termaline Load Re- Start-up sistor to the transmitting equipment under test with 50 ohm coaxial cable such as RG-213/U or equal, equipped with a Male N type plug (UG-21E/U or equal) which mates with the RF input connector of the load.
  • Page 14: Emergency Shutdown

    Bird Model 8141 Termaline Load Resistor Emergency Shutdown WARNING Never attempt to disconnect RF equipment from the transmission line while RF power is being applied. Leaking RF energy is a potential health hazard. Turn off the equipment by removing power from the RF gen-...
  • Page 15: Maintenance

    Chapter 5 Maintenance Troubleshooting For corrections requiring repair or replacement of compo- nents, refer to the appropriate section for your specific model. Table 1 Problem Possible Cause Correction Troubleshooting Coolant oil leak Clamping bands not Tighten slightly with around clamping tight screwdriver band or radiator...
  • Page 16: Inspection

    Bird Model 8141 Termaline Load Resistor Inspection With the rugged and simple construction of loads, periodic inspection will be necessary at only about six month inter- vals. Inspection should include the items listed below: Cleanliness - Keep the housing and connector free of grime.
  • Page 17: Disassembly

    Maintenance with an accuracy of one percent or better at 50 ohms for this purpose. If the load is used frequently, daily to weekly, it would be wise to check the resistance on a monthly schedule. If how- ever, the load is used more infrequently you may want to set up a six month to yearly schedule accordingly.
  • Page 18: Rf Input Connector

    Inspect the O-Ring seal just inside the sloped flange of the mounting ring. Re- place this seal, Bird P/N 5-230, if it shows any evidence of cuts or deterio- ration such as hardening or surface cracks.
  • Page 19: Repairs

    Beryllia oxide must be disposed of in accordance with the legal statutes dealing with hazardous material. Do not attempt to repair this unit, but return to BIRD ELECTRONIC CORPORATION. Repairs beyond what is covered in this instruction book will require return of the equipment to Bird Electronic Corpora- tion for service.
  • Page 20: Storage

    Bird Model 8141 Termaline Load Resistor No special preparation for storage is required other than to Storage cover the equipment to keep it free of dust and dirt accumu- lations. Storage in a dry, dust and vibration free environ- ment is recommended. The storage temperature should preferably remain within the working temperature range of -40°C to +45°C (-40°F to +113°F).
  • Page 21 Models: 8140-010 8141 The undersigned hereby declares, on behalf of Bird Electronic Corporation of Cleveland, Ohio, that the above-referenced product, to which this declaration relates, is in conformity with the provisions of the following standards; European Standard EN 61010-1:1993 - Safety, Group II.
  • Page 22 Limited Warranty All products manufactured by Seller are warranted to be free from defects in material and workmanship for a period of one (1) year, unless otherwise specified, from date of shipment and to conform to applicable specifications, drawings, blueprints and/or samples. Seller’s sole obligation under these war- ranties shall be to issue credit, repair or replace any item or part thereof which is proved to be other than as warranted;...
