CE Compliance
Electrostatic discharge
(ESD)
Drop Tested
Transit Drop
Bench Handling
Vibration
Shock, Functional
Drip Proof
Salt Exposure
Fungus Resistance
Explosive Atmosphere Per MIL-PRF-28800F 4.5.6.3
Available Upgrades
General
Applications
General Specifications
EN 61326-1:2006 – Part 1,
EN 61326-2-1:2006 – Part 2-1
EN 6100-4-2:1995, A1:1998 & A2:2001 inclusive,
Directive 2004/108/EC Relating to Electromagnetic
Compatibility
Standard: EN 61326-1:2006 Electrical equipment for
measurement, control and laboratory use - EMC
requirements - Part 1: General requirements (IEC 61326-
1:2005)
Meets level B criteria for all test except EN 6100-4-2,
Section 2 ESD immunity test, meets level C.
Directive 2006/95/EC on low voltage
Standard EN 61010-1:2001 Safety requirements for
electrical equipment for measurement, control, and
laboratory use — Part 1: General requirements (IEC
61010-1:2001)
Federal Register CFR 47, Part 15, subpart B: 2005,
Class A
ICES-003, Rev. 4:2004, Category II Equipment, Class A
This equipment is not specified to operate in an
environment where it may be subjected to an ESD voltage
spike directly on the metal portion of the enclosure.
1 meter drop in most severe position per EN 61010-1
10 drops on corners and faces per MIL-PRF-28800F,
Class 2
4 drops on each face per MIL-PRF-28800F, Class 2
Random 10 to 500 Hz per MIL-PRF-28800F, Class 2
30 G half-sine shock pulse per MIL-PRF-28800F, Class 2
Water flow 16 liters per hour per MIL-PRF-28800F, Class 2
Salt fog tested for 48 hours, constantly wetted with 5%
salt solution at 35°C per MIL-PRF-28800F, Class 2
5 species for 28 days at 30°C and 95% humidity per MIL-
PRF-28800F, Class 2
From any other model to SH-362S
General Measurement Features
Cellular, PCS, DCS, 2G, 3G, 4G, CDMA, cdmaOne, CDMA 2000,
1x, 1x EV-DO, GSM, GPRS, EDGE, UMTS, HSDPA, W-CDMA,
TDMA, AMPS, 802.11, Bluetooth, Broadcast, Emergency, Fire,
GPS, HDTV, IBOC, In-Building, Lab, LMR, Microwave, NPSPAC,
Paging, Police, Private, Project 25, Public Safety, Tactical Military,
Telematics, Tetra, Trunking, Utilities, WiMAX, WLAN, and WLL.
145
