Predefined Measurements
Chart I - Distortion & DANL
For Vector Network Analyzer (Models SH-362S, SH-362, & SH-361S Only)
Range
Resolution
Accuracy
Span
Span
Sweep Time
Measurement
Points
IF Bandwidth:
Measurements
Spectrum Analysis, Occupied Bandwidth (OBW),
Channel Power, Adjacent Channel Power Ratio
(ACPR), Field Strength, Time Domain, AM/FM
Demodulation, Carrier-to-Interference Ratio (C/I),
and Water Fall Spectrogram.
Emission Masks for broadcast, LMR, and WiMax
applications.
Out-of-Band Spurious and In-Band, Out-of-
Channel Spurious measurements.
Frequency
1.6 MHz to 3.6 GHz
40.323 kHz
± 10 kHz or ±10ppm whichever is greater
100 kHz – 3.6 GHz
100 kHz to 3598.4 MHz
<0.6 sec 705 points, reflection measurement, IF BW
1MHz
<0.6 sec 705 points, thru measurement, IF BW 1MHz
12,23,45,89,177,353,705,1409,2817,5633,11265
Calibrated at point counts 705 and above
100 Hz to 3 MHz in 1,3,10 steps
139
