Chart II - Return Loss Uncertainty, 1.6MHz to 3.6GHz

Chart III - Insertion Loss/Gain Uncertainty, 1.6 MHz to 3.6 GHz
Model
Housing
142
General Specifications
Name: SignalHawk
Model: SH-36S, SH-361S, SH-362, and SH-362S
Component: Spectrum Analyzer, 1-Port Vector Network
Analyzer, and 2-Port Vector Network Analyzer
PC/ABS housing, rubber over-mold and shock-mounted
hardware.
