Display
Ambient Light Sensor Ambient light sensor automatically adjusts display
Keypad
Buttons
Power Indicator
Charge Indicator
Audio
Connectors
Lanyard Connect
Stand
General Specifications
8.4" diagonal (34 sq in), TFT, LCD, full color, SVGA, 800
x 600 pixels, 120 dpi, dual-backlight, viewable indoors
and outdoors
backlight when in auto backlight mode.
Single-piece integrated unit is sealed to protect against
water. In addition, it protects against impacts to display.
Power On/Off
Mode
Setup
Enter
Escape/Back keys
Left, right, up, and down arrow keys
Thumbwheel
6 yellow soft keys along bottom of display
8 blue soft keys to right of display
12-key numeric keypad (0-9.+/-)
Green LED labeled "Power".
On continuously when operating.
Amber LED labeled "Charge".
Slow blink rate (2.5 s) when charging battery.
On continuously when battery fully charged.
Rapid blinking when battery disconnected, failed or wall
adapter problem.
Internal speaker and external headphone
N(F) for RF input
2.5mm DC Jack for AC adapter/charger external power
USB Type A for USB drive and accessories
USB Type B for PC connection
RS-232 DB-9(F) for external power sensors
BNC(F) for external trigger (Spectrum Analyzer models)
3.5mm for mini-headphone
RJ-45 LAN jack for factory diagnostics only
Two reinforced features for attaching a lanyard and/or other
quick attach/release connector. Reinforcing supports > 10 lbs.
Stand can open to angles of 15°, 45°, 180°, or close flat. May
use as desk/bench top stand, carry handle, or hook hanger.
