Measures the signal duty cycle. Select Auto or Manual, the

Duty Cycle -

default setting is Auto. See "Configure" on page 120.
Note: For additional information about duty cycle, refer to the
owner's instruction book for the WPS.

Manual Duty Cycle -

cent. See "Configure" on page 120.
Note: Use this feature if the duty cycle is known and if the burst is
less than 10 W.

CCDF Limit (Complimentary Cumulative Distribution Function) -

Allows use of the key pad to enter a wattage limit for CCDF. See "Configure" on
page 120.
Note: Set the limit before selecting the CCDF
Measurement Type.
Note: For additional information about CCDF, refer to the owner's
instruction book for the WPS.

Range Select -

100 μW to 1 MW and Auto in the following sequence: Auto, 100 μW, 1 mW, 10
mW, 100 mW, 1 W, 10 W, 100 W, 1 kW, 10 kW, 100 kW, 1 MW, 150 mW, 1.5 W,
15 W, and 150 W. The default is Auto. See "Configure" on page 120.

Menu Keys and Associated Soft Key Functions

Zero

Starts a zero calibration of a sensor.
Note: For additional information, refer to the owner's instruction
book for the sensor.

Type

Note: Specific measurement types depend upon the power sensor being
used (Figure 98, Directional sensor or Figure 99, Wideband sensor). Not
all power sensors have the Type selection option.
Soft key functions that select the primary measurement to be made (such as for-
ward average power, reflected average power, match) are enabled. The selected
measurement will be displayed in large characters above the bar graph. The remain-
ing measurements will display in smaller characters below the bar graph. If one of
the measurements is not available or does not apply to the current application, it
will be identified as N/A (not applicable) in the Sensor Readings area of the screen.
