Looking at the Screen

When the SignalHawk is connected to an external power sensor, the available
commands will vary according to the capabilities of the sensor being used. Typi-
cal functions are for selecting the type of measurement, type of element, units
of measure, measurement scales, offset values, and zeroing the sensor.
When a power sensor is properly connected (and detected), the status mes-
sage, located at the top of the Power Meter screen, will indicate the model
number of the power sensor (i.e., Bird model number).
Figure 97 Power Sensor Initial Screen
Item
1 Model of connected power sensor
2 Soft Key Labels
3 Power Supply
4 Menu Label Keys
5 Sensor Help Text
6 Sensor Readings
7 Power Display
8 Main Power Display
114
Description
