Match: Rho

Measures match, a complex ratio of reflected power to forward average power
expressed in Rho.
 
Rho = Sqrt Pr Pf

Match Efficiency %

Measures match, a complex ratio of reflected power to forward power expressed
in percent efficiency.
MatchEfficiency Percent

Forward Average

Measures the forward average power.
  
Pf dBm = 10

Reflected Average

Measures the reflected average power.
  
Pr dBm = 10

Match

Measures the match between the transmitted forward average power and the
reflected average power.
MatchEfficiency Percent

Forward Peak

Measures the forward peak envelope power.

Forward Burst

Measures the average power of a transmitted pulse.

Crest Factor

Measures the difference between the peak power and the average power.

 
= 100
   
Log Pf Watts
   
Log Pr Watts
 
= 100
     
1 – Pr Pf
+ 30dB
+ 30dB
     
1 – Pr Pf
